Technical Data:
Model |
TA8121 |
TA8123 |
Maximum display |
3 1 / 2 digit LCD display, maximum reading 1999 |
|
Measuring range |
200Lux,2000Lux,20000Lux,100000Lux |
200Lux,2000Lux,20000Lux,200000Lux |
Display resolution |
200lux gear: 0.1 lux, other gears 1Lux |
|
Accuracy |
±3% rdg ± 10dgts(When less than 10,000 lux ) |
|
±4% rdg ± 10dgts (When more than 10,000 lux ) |
||
(Adjusted by colour temperature 2856 K standard flat lamp) |
||
Photoreceptor |
Photodiode with filter lens |
|
Repeat the test |
±2% |
|
Sampling rate / measurement speed |
About 2 times per second |
|
Range conversion |
Manual or automatic measurement |
|
Maximum and minimum measurement |
Yes |
|
Lux / FC conversion function |
Yes |
|
Low voltage prompt |
Yes |
|
Automatic data acquisition and recording |
It can automatically record 50 measurement data (with delay time recording function, 1 ~ 60 seconds optional) |
|
Power supply |
1.5V x 2 AAA batteries |
|
Working environment temperature |
0 ℃ to 50 ℃ |
|
Working environment humidity |
10 ~ 95% RH - non condensing |
|
Storage temperature |
-20 ℃ to 60 ℃ (excluding battery) |
|
Standard accessories |
Cloth bag, instruction manual, certificate, AAA battery * 2 |
|
Package size |
185 x 55 x 30mm |
|
Package method |
Color box+ Cloth bag |
|
Product net weight |
About 150g |
|
Individual package size |
220 x 95 x 55mm |
|
Individual package weight |
0.27kg |
|
Standard outer box volume (L x W x H) |
45x29x40cm |
|
Standard packing quantity |
40PCS |
|
Standard packing weight |
About 12kg |
