LP Adapters JIC to NPT Stainless Steel

LP Adapters, JIC to NPT, Stainless Steel

LP (Max 15k PSI)Adapters

JIC standard adapters with 37° flare tube connection for JIC 04, 06, 08 and 16 to NPT tubes sizes 1/4", 3/8", 1/2", 3/4" and 1". Compact designs, made from NACE certified AISI 316L / EN1.4404 stainless steel for maximum life.

Giá: 0932182327

Mã sản phẩm: JIC male to NPT male

Model: 199502130, 199502131, 199502132, 199502133, 199502134, 199502135, 199502136, 199502137, 199502138, 199502139, 199502140, 199502141

LP Adapters, JIC to NPT, Stainless Steel (Max 15k PSI)
Part No.	Category	Rec. torque (Nm)	Connection 1	Connection 2	Max working pressure
199502130	JIC male to NPT male	conn.1: 18 conn.2: 29 Nm	JIC 04	1/4" NPT	69.0 MPa
199502131	JIC male to NPT male	conn.1: 18 conn.2: 34 Nm	JIC 04	3/8" NPT	69.0 MPa
199502132	JIC male to NPT male	conn.1: 18 conn.2: 61 Nm	JIC 04	1/2" NPT	69.0 MPa
199502133	JIC male to NPT male	conn.1: 30 conn.2: 29 Nm	JIC 06	1/4" NPT	69.0 MPa
199502134	JIC male to NPT male	conn.1: 30 conn.2: 34 Nm	JIC 06	3/8" NPT	69.0 MPa
199502135	JIC male to NPT male	conn.1: 30 conn.2: 61 Nm	JIC 06	1/2" NPT	69.0 MPa
199502136	JIC male to NPT male	conn.1: 64 conn.2: 29 Nm	JIC 08	1/4" NPT	69.0 MPa
199502137	JIC male to NPT male	conn.1: 64 conn.2: 34 Nm	JIC 08	3/8" NPT	69.0 MPa
199502138	JIC male to NPT male	conn.1: 64 conn.2: 61 Nm	JIC 08	1/2" NPT	69.0 MPa
199502139	JIC male to NPT male	conn.1: 64 conn.2: 102 Nm	JIC 08	3/4" NPT	69.0 MPa
199502140	JIC male to NPT male	conn.1: 64 conn.2: 163 Nm	JIC 08	1" NPT	69.0 MPa
199502141	JIC male to NPT male	conn.1:169 conn.2: 163 Nm	JIC 16	1" NPT	69.0 MPa
